Name: SHACMAN X5000 Tractor Head with 400L Fuel Tank 12R22.5 Tires and WEICHAI Engine 6x4 460HP EuroV Red
Brand: SHAAN XI HAN OCEAN CO . , LTD
SKU: X5000
Price: 42.00 USD
Availability: InStock

Maison > produits > Camion de tracteur >

SHACMAN X5000 Tractor Head with 400L Fuel Tank 12R22.5 Tires and WEICHAI Engine 6x4 460HP EuroV Red

400L Fuel Tank Tractor Head

12R22.5 Tires Truck Tractor Head

WEICHAI Engine SHACMAN X5000 Tractor

Lieu d'origine:

Shaanxi, Xian

Nom de marque:

SHACMAN

Certification:

ISO9001/CCC

Numéro de modèle:

X5000

Nous contacter

Demandez un devis

SHACMAN X5000 Tractor Head with 400L Fuel Tank 12R22.5 Tires and WEICHAI Engine 6x4 460HP EuroV Red

Détails de produit

Modle:

SX42584X324

Moteur:

WP12.460E50

Transmission:

12JSD200T-B

Essieu:

Double-étape de 7.5T /2 *13 T, vitesse Ratio-4.769

Base de roues:

3175+1400mm

Pneu:

12R22.5

Réservoir à carburant:

400L

Embrayage:

φ430 Embrayage à ressort de diaphragme

Entrée d'air:

Filtre à air ordinaire

Châssis:

(940-850) X300 (8) simple

suspension:

Ressort de plat multicouche de /rear d'avant

Cabine:

Haut toit prolongé

Couleur:

Vert rouge/vert au néon de montagne/bleu/eau-de-vie fine bleus Aurora White /Klein d'étoile et de lu

Mettre en évidence:

400L Fuel Tank Tractor Head

12R22.5 Tires Truck Tractor Head

WEICHAI Engine SHACMAN X5000 Tractor

Conditions de paiement et d'expédition

Quantité de commande min

Prix

negotiable

Détails d'emballage

Un paquet nu, avec de la cire avant expédition.

Délai de livraison

30 jours ouvrables

Conditions de paiement

T / t, l / c

Capacité d'approvisionnement

5000 unités/mois

Produits connexes

Nous contacter

Contact maintenant

Description de produit

SHACMAN X5000 Tractor Head 6x4 460HP EuroV Red Truck Tractor Head

Detailed Product Description

Model: SX42584X324
Drive type: 6x4
Weight: Gross Vehicle Weight≤50
Engine Brand: WEICHAI
Engine Model: WP12.460E50
Engine Power: 338kw / 460Hp
Gear box Brand: FAST
Gear box Model: 12JSD200T-B

Tractor Truck Parameters

Model	SX42584X324
Drive type	6x4
Weight	Gross Vehicle Weight ≤50
Dimensions	Wheelbase/(mm) 3175+1400
Performance	Maximum speed/(km/h) 45～60/90
Ground clearance	>314
Engine Brand	WEICHAI
Engine Model	WP12.460E50
Engine Power	338kw / 460Hp
Maximum torque	2110 N*M
Displacement	12.596 L
Emission standard	Euro V
Gear box Brand	FAST
Gear box Model	12JSD200T-B
Clutch Type	φ430 Diaphragm spring clutch
Cooling Type	Domestic heat sink
Air inlet Type	Ordinary air filter
Brakes Type	Drum brake
Service brake	Double circuit air brake
Park brake	Rear wheel spring brake
Auxiliary brake	WEVB engine exhaust brake
Steering Type	ZF8098 technology, circulating ball steering machine
Chassis Type	Parallel trapezoidal frame with variable section
Chassis Dimensions	(940-850)X300(single 8)
Suspension Front	Multi-layered leaf springs
Suspension Rear	Multi-layered leaf springs
Axles Brand	HANDE
Front axle	7.5T front axle MAN technology
Rear axle	13T MAN Double Reduction Drive axle with inter helix differential and differential lock, bridge speed ratio: 4.769
Tires Type	12R22.5
Fuel tank capacity	400L Aluminum tank
Electrics Type	24V
Battery	165Ah Maintenance-free battery
Cab Type	SHACMAN X5000 Extended High Roof cab
Cab Equipment	Air main seat, four-point air-suspended cab, electronically controlled automatic temperature-controlled air conditioning, electric window rollers, manual flip, telescopic axle maneuvering, regular 50 saddle, split fenders, 165Ah maintenance-free battery, SHACMAN logo, full English logo.

Tractor Truck Advantages

The X5000 tractor is equipped with a more powerful 460-horsepower engine that provides extra power for demanding transport tasks. The added horsepower improves acceleration, climbing ability, and overall performance.
SHACMAN trucks prioritize driver comfort, and the X5000 is no exception. The cabin is designed to provide a comfortable and ergonomic environment with air conditioning, adjustable seating and ample storage space. This helps reduce driver fatigue during long journeys, contributing to a safer and more enjoyable driving experience.

FAQ

1. Who are we?

We are based in Shaanxi, China, start from 2015, sell to Africa (70.00%), Southeast Asia (10.00%), Central America (10.00%), South America (4.00%), Mid East (2.00%), Eastern Asia (2.00%), South Asia (2.00%). There are total about 11-50 people in our office.

2. How can we guarantee quality?

Always a pre-production sample before mass production; A comprehensive final inspection is conducted prior to shipping to ensure the highest standards of quality and compliance are met.

3. What can you buy from us?

Dump truck, track truck, lorry truck, Van truck, Mixer truck.

4. What services can we provide?

Accepted Delivery Terms: FOB, CFR, CIF, EXW, CIP, DDU； Accepted Payment Currency: USD, EUR, CNY; Accepted Payment Type: T/T, L/C, D/P D/A Language Spoken: English, French
